60CBM Commercial Refrigerated Walk-in Storage Small Cold Room for Fruit and Vegetable

Availability:
  • HBE-FE-7C1

  • Highbright

  • HBE-FE-7C1

Product Description

01

Cold room structure

Linble cold room consists of cold room panel (PU sandwich panel), cold room door, condensing unit, evaporator (air cooler),temperature controller, air curtain, copper pipe, expansion valve and other refrigeration fittings.

Cold room applications

Cold room is widely used in food industry, medical industry, and other related industries.

In food industry, cold room is usually used in food process factory, slaughterhouse, fruit and vegetable warehouse,supermarket,hotel, restaurant, etc.

In medical industry, cold room is usually used in hospital, pharmaceutical factory, blood center, gene center, etc.

Other related industries, such as chemical factory, laboratory, logistics center, they also need cold room.

Design Princple

02

1.What is the application of the cold room?

It will affect the temperature of cold room needed to be, and the choice of thickness of pu panel and material covered on panel.

2.What is the size of the cold room?

It will affect the choice of condensing unit and air cooler, basing on the cold room temperature.

3.Which country will the cold room be located in? How about the climate?

It will affect the choice of voltage and condenser, if the temperature is high all the year, we need to choose condenser with bigger evaporation area.

Application for example
Room Temperature
Fruit & Vegetable
-5 to 10 ℃
Chemical factory,medicine
0 to 5 ℃
Ice cream, ice storage room
-10 to -5 ℃
Frozen meat storage
-25 to -18 ℃
Fresh meat storage
-40 to -30 ℃


Solution and Catalog

General details of fresh cold room

Reference   dimension(L+W*H)6m*4m*2.5m8m*5m*2.5m10m*6m*2.5m11 m*6m*3m
ApplicationUsully   for storage offresh vegetables and fruits
Temperature-5℃~+5℃
Power380V/50HZ/3Phase   (can be customized)
Cold   room structure
Surface metal (Take PPGI on both sides for example)0326mm   PPGI0.326mm   PPGI0.326mm   PPGI0.326mm   PPGI
Thickness of PU panel100mm100mm100mm   a100mm
Cold room door(W+H)Hinged   door 0.8m*1.8m _Hinged   door 0.8m*1.8mManual   slidig door 1.5m*2mManual   sliding door 1.8m*2m
Refrigeration   Equipment
Compressor brandGermany   Bitzer 上Germany   BitzerGermany   BitzerGermany   Bitzer
Compressor typeSemi-hermeticSemi-hermeticSemi-hermeticSemi-hermetic
Compressor model4FES-5Y4DES-7Y4VES-10Y4PES-15Y
RefrigerantR404aR404aR404aR404a
Condenser modelFNH-12.   5/41FNH-17/60FNH-23/80FNH-35/120
Evaporator   model DD30 DD60 DD80 DD120

General details of freezr cold room

Reference   dimension(L*W*H)4m*4m*2.5m6m*4m*2.5m6m*6m*2.5m6m*8m*2.5m
ApplicationUsually   for storage of frozen fish, meat and seafood
Temperature-20"   C~-18"C
Power380V/50HZ/3Phase   (can be customized)
Cold   room structure
Surface metal (Take PPGI on both sides for example)0.326mm   PPGI0.326mm   PPGI0.326mm   PPGI 40.326mm   PPGI
Thickness of PU panel150mm1   50mm150mm1   50mm
Cold room door(W+H)Hinged   door 0.8m*1.8mHinged   door 0.8m*1.8mManual   sliding door 1.5m*2mManual   sliding door 1.5m*2m
Refrigeration   Equipment
Compressor brandGermany   BitzerGermany   BitzerGermany   BitzerGermany   Bitzer
Compressor typeSemi-hermeticSemi-hermeticSemi-hermeticSemi-hermetic
Compressor model4DES-5Y4TES-9Y4PES-12Y4HE-18Y
RefrigerantR404aR404aR404aR404a
Condenser modelFNH-12.5/41FNH-17/60FNH-23/80FNH-35/140
Evaporator modelDD30DD60DD100DD140

General details of blast cold room


Reference   dimension(L*W*H)2.5m*25m*2.4m4m*3m*2.5m
ApplicationUsully   for fresh fish, fresh meat and fresh seafood
Temperature-40"C~-35°C
Power380V/50HZ/3Phase   (can be customized)
Cold   room structure
Surface metal (Take PPGI on both sides for example)0.326mm   PPGI0.326mm   PPGI
Thickness of PU panel150mm150mm
Cold room door(W+H)Hinged   door $ 0.8m*1.8mHinged   door 0.8m*1.8m
Refrigeration   Equipment
Compressor brandGermany   BitzerGermany   Bitzer
Compressor typeSemi-hermeticSemi-hermetic
Compressor model10HP   4PES-12Y30HP   6GE-34Y
RefrigerantR404aR404a
Condenser modelFNH-23/80FNV-64.5/240
Evaporator modelDJ55DJ170
